MSV - MULTI SCALER VIEWER - Video

The MSV, Multi Scaler Viewer is an advanced video processor for multimedia presentations. It is an ideal solution for applications where up to four different or same video signals must be displayed on a single display. MSV allows you to manipulate output images, wherever positions and whatever size you want for display and also allows you to control brightness, overlay, etc. The embedded scaler converts signals from input source to match user-selectable output setting up to 1080p. MSV uses modular type DVI, D-Sub, SDI and HDMI input cards and DVI output cards to have flexibility on application and to reduce cost by avoiding purchase of additional equipment. MSV control is available via front panel control, user interface program (MSV Manager) on Windows and RS-232. Main functions: ● Various types of modular type Input cards (*Only available for DVI and SDI, Not available for HDMI, D-SUB at 2016 04) ● Allow various resolution inputs ● Selectable output resolutions ● Copy window and Pan&Zoom ● Adjustable window size and position ● Window labeling ● Overlay ● 1 selectable audio output among 4 audio inputs ● Contrast, Brightness, Border control ● User preset window layout saving
