NAKAMURA TOME TW20 MM Twin-Spindle CNC Lathe with Motorized Tools
- Current bid
- Status
€
Total bid amount
See total breakdown
Total bid amount
See total breakdown
€
Max bid amount
See total breakdown
Max bid amount
See total breakdown
Lot specifications
- Quantity
- 1
- Margin
- No
- Brand
- NAKAMURA TOME
- Type
- TW20 MM
- Year of build
- 1992
- Machine weight
- 5500kg
- Dimension l
- 3500mm
- Dimension w
- 2800mm
- Dimension h
- 2000mm
- Terms of delivery
- Loaded on truck
Description
CNC lathe for turning and machining metal parts.
CNC control: Fanuc 16 T AA
Max. turning diameter: 165 mm
Turning length: 100 – 340 mm
Diameter above bed: 220 mm
Main spindle speed: 50 – 5,000 rpm
Main spindle power: 5.5 / 7.5 kW
Main spindle bar passing: 65 mm
Sub-spindle speed: 50 – 5,000 rpm
Sub-spindle power: 3.7 / 5.5 kW
Sub-spindle bar passage: 42 mm
C-axis: 0.001°
Turrets: 2
Tool positions: 2 × 16
Motorized tools: 2 × 16 positions
Strokes: X 175 mm / Z 240 – 680 mm
Total power: 41 kVA
Dimensions (mm): 3,500 × 2,800 × 2,000
Weight (kg): 5,500
CNC control: Fanuc 16 T AA
Max. turning diameter: 165 mm
Turning length: 100 – 340 mm
Diameter above bed: 220 mm
Main spindle speed: 50 – 5,000 rpm
Main spindle power: 5.5 / 7.5 kW
Main spindle bar passing: 65 mm
Sub-spindle speed: 50 – 5,000 rpm
Sub-spindle power: 3.7 / 5.5 kW
Sub-spindle bar passage: 42 mm
C-axis: 0.001°
Turrets: 2
Tool positions: 2 × 16
Motorized tools: 2 × 16 positions
Strokes: X 175 mm / Z 240 – 680 mm
Total power: 41 kVA
Dimensions (mm): 3,500 × 2,800 × 2,000
Weight (kg): 5,500
Additional details
The dimensions and weights indicated for each batch are provided as a guide and correspond to the current configuration (assembled machine).
Disassembly, handling or packaging operations can change this data and impact transport conditions.
Before any transport is organised, buyers are invited to check the real characteristics of their lots directly with the seller or the company in charge of dismantling.
